Overview

  • FULLY LAYOUT WITH 2 X 360 LINE LASERS- One 360° horizontal and One 360° vertical planes enable users to measure and mark all around the room. Horizontal line and vertical line cross at 90°angles makes user quickly visualize and finish square layout. This 360 laser level is a complete level tool as well as an alignment laser aids in full room layout.

  • TRIPLE POWER TECHNOLOGY- Huepar 602CG employed the included large capacity lithium battery (can be purchased easily at local market) for extended run-time, or with 4 AA alkaline batteries. In addition, this laser tool can be used at job site with direct input charging even if take out the battery. Charging protection help prevent the tool from overcharge. 4 battery indicators on keypad allow users to know the current battery volume anytime.

  • MULTIFUNCTIONAL MODE- The horizontal and vertical 360° laser lines can be switched individually or together. With our smart pendulum system, this laser level tool self levels and indicates out-of-level condition while pendulum unlocked. Once pendulum locked, it switches to manual mode to lock lines for use at any angle.

  • POWER-SAVING OUTDOOR PULSE MODE- This laser level projects green laser beam which is 4 times brighter than standard red beams with a working range up to 130Ft with an accuracy of +/- 1/9" at 33Ft. Besides highly visible green beam, a power-saving pulse mode extends laser range up to 200Ft with Huepar LR-5RG Line Laser Receiver in bright light or outdoor conditions and continuous working time.

  • DURABLE DESIGN & WARRANTY- Over-molded housing with IP54 water/dust resistance ensures users work well in hazardous working conditions. The laser tool also offers 1/4"-20 and 5/8"-11 mounting threads to suit different tripod threads. Strong magnetic pivoting base allows for attachment to metal track and steel. 12 months limited warranty up to 24 months if become a royal member through product registration.



 602CG Laser Level Specifications:

  • Laser Class: Class 2 (IEC/EN60825-1/2014), output power <1mW

  • Laser Wavelength: 505-520nm

  • Leveling Accuracy: ± 1/9 Inch at 33 Feet

  • Horizontal/Vertical Accuracy: ± 1/9 Inch at 33 Feet

  • Leveling/Compensation Range: 4°±1°

  • Working Distance with Huepar Receiver: 200Ft

  • Operating Time with Lithium Battery: 7 hours with all laser beams on

  • Operating Time with AA Batteries: 4 hours with all laser beams on

  • Power Source: Li-ion battery&4×˝AA˝ (LR6) batteries

  • Operation Temperature Range: 14℉ ~ 113℉ (-10℃~ 45℃)



WARNING: Avoid direct exposure of the laser beam to the eyes.





Technical Details




Self-leveling mode & Manual mode



Self-leveling mode:

When the laser tool is switched to the unlocked position, self-leveling mode is enabled. The laser beam will blink continuously at 2Hz when the tool is beyond self-leveling range (4°±1°).


Manual mode:

When the pendulum lock is in locked position, you can place the laser tool at various angles to project non-level straight lines. The laser beam will blink every 3-5 seconds to remind you that it's not self-leveling now.




Pulse Mode

  • Turn ON pulse mode: After power on, short press the button besides the power button to turn on the pulse mode. The indicator will light up in red.

  • Pulse mode extends the working range up to 200Ft in bright working conditions, using with Huepar Line Laser Receiver.

  • When use with a receiver, it’s necessary to turn on the pulse mode.

  • It is compatible with Huepar LR-6RG Line Laser Receiver only.




Easy Use

  • Durable design: Over-molded housing with IP54 water/dust resistance ensures you work well in hazardous working environments.

  • Green Target Plate: Increases the visibility of the laser beam.

  • 360° Strong Magnetic Pivoting Base: Allows for attachment to metal track and steel,supporting you to turn the laser level around at 360 degree , projecting lines at any angle

  • Two Mount Sizes: 1/4"-20 and 5/8"-11 mounting threads for temporarily fastening in place or being fixed on tripod.




Triple Power Supply

  • This laser tool utilizes the included large capacity lithium battery which is compatible with Samsung SB-L110 battery.

  • This laser tool comes with an holder for installing AA battery for using the tool.

  • Direct input charging: This laser tool can be used at job site with direct input charging even if take out the battery.

  • Charging protection help prevent the tool from overcharge.



Find your perfect laser level

Customer Reviews

No reviews yet
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Endorsed By

≥ 5,000 times Button test

All buttons are tested to ensure proper functionality.

≥ 5,000 times Switch test

The switch is tested repeatedly to ensure that the machine works stably.

≥ 1,000 times Charging test

Make sure the charging interface is working properly and not loose.

≥ 500 hours Working test

Laser tube aging test to ensure no brightness attenuation.

IP54 extreme environment test

Waterproof and dustproof, ensuring normal use in dusty environments.

Natural drop and shock test

Simulate natural drops while maintaining accuracy.

Simulated transportation

Simulate complex transportation environments to ensure unchanged accuracy.

High and low temperature test

Make sure the device can work normally between -10℃ ~ 50℃

High Quality Ensured by Professional Testing

Every product goes through 8 strict inspection processes before it is delivered to you to ensure that you receive products of consistent quality.
